U12m
UHF Wiegand Reader With Web API Supported(12m distance)
Fingerprint
Face Recognition
RFID Card
LAN
WiFi
GPS
Overview
U12m is a high-performance UHF Wiegand RFID reader designed for long-range access control applications. With a powerful reading capability of up to 10-12 meters, it is ideal for vehicle access, gated communities, and industrial entrances.
Key Features
- Reads UHF RFID tags from a distance of up to 12 meters
- Operating frequency range: 860 MHz to 960 MHz
- Built with a rugged die-cast aluminium body
- IP66 waterproof rating for outdoor installations
- Wiegand interface for seamless integration with full access control systems
Web API Integration
To enable Web API functionality and communicate with remote web applications, this reader must be connected to a compatible full access control system. Once paired, it can seamlessly push real-time data to your web server through our supported Web API.
Supported access control systems: RSP10i3, RSP10i4, RSP10i5, RSP10f1, RSP10t1, RSP10t9
For developers, complete integration details are available in our Web API Documentation.
Note: This product only provides the reader. For complete integration, pair it with one of the supported access control systems listed above.
Specifications
Card Capacity
Unlimited
Transaction Storage
Unlimited
Identification Speed
>150 tags/sec
Identification Mode
Card
Power Supply
9~12V DC
Operating Temperature
-20o C - -60oC
Battery
No
Cloud Supported
Yes
API Supported
Yes
Communication
Wiegand 26(Default), Wiegand 34
Ingress Protection Rate
IP66
Dimension
445mm x 445mm x 35mm
Operating System
All OS Types
Volumetric Weight
4 kg
Weight
2.5 kg
Compatible OS
All OS Types
Reading Distance
10m to 12m
Frequency
902Mhz - 928Mhz, 865MHz - 868MHz
Shell Material
Die-casting aluminum shell, Antenna panel with engineering plastics
Working Voltage
9~12V DC
Interface Protocol
EPC global UHF Class 1Gen 2/ISO 18000-6c
Working Mode
Always Reading
