SlimBeast (i33) - Fingerprint Time Attendance and Access Control System
This access control device has a highly elegant design, touchpad, and is lightweight. It supports fingerprint, card, and password authentication and has a 2-inch TFT display with clear menu options. It is suitable for use in well-designed offices and can be optionally upgraded to be IP67 waterproof.
If used as an attendance machine, the first recorded attendance of the day will be considered IN, the next OUT, and so on.
The device features a fingerprint/card exit reader and a push-button for exit. It can be upgraded to include WiFi connectivity. Despite being a high-end model, it comes at a competitive price in the global industry for such features.
Note: The device only supports numerical user IDs when adding users and does not support break in/out. The supported exit reader is the RC12 Exit Reader.
The device supports four automatic punch states:
- Treat all punches as IN.
- Treat all punches as OUT.
- Treat the first entry as IN, the next as OUT, and so on.
- Treat the first entry as IN and the rest as OUT.
If you'd like to link the device with your own web application, you can refer to the provided WEB API Documentation.
Specification
Fingerprint Capacity | 3000-5000 |
---|---|
Card Capacity | 3000-5000 |
Transaction Storage | 200,000 |
CPU | 1 Ghz |
Identification Speed | <1 scond |
TFT Display | 2.8' Inch TFT |
Power Supply | 9v 1A |
Battery | No support |
Cloud Supported | Yes, Buy etsCouncil |
API Supported | Yes, Buy API |
LAN Supported | Yes |
GPRS/GSM Enabled | N/A |
WIFI Enabled | Optional |
USB Supported | Yes |
Communication | TCP/IP, HTTP |
Ingress Protection Rate | N/A |
Access Control | Full Access Control, |
Supported Exit Readers | RC12, RC24, RC15 |
Push Data | Yes, Buy API 3.0 |
Dimension | 140*44*20mm (H x W x L) |
Operating System | Windows, Linux, Mac |
Volumetric Weight | 1.5kg |
Weight | 0.500 kg |
